Contact angle measuring instrument, water drop angle measuring instrument

Equipment overall parameters

Model	SDC-200S
Types of	research type
Specification（LWH）	800190640mm
Weight	16kg
Material of base	aviation aluminum

Sample platform system

Experimental platform	160mm*200mm
Platform move	Manual (upgradeable to automatic)
Platform movement range	60mm35mm80mm
Platform tilt	Manual tilting platform (optional) Electric tilting platform (optional)

Acquisition System

Camera	U3.0
Type of lens	High Fidelity Microscope Lens
Lens magnification	10x
Zoom	±3mm
Maximum shooting speed	200 frames/s more models optional
Front and rear adjustment of the lens	30mm
Lens tilt adjustment	±10°

Injection system

Drop sample	Automatic aspiration and injection
Wetting liquid	Manual (upgradeable to automatic)
Dripping accuracy	0.01 μL scalable picoliter system
Liquid injection movement method	Manual (upgradeable to automatic)
Liquid injection movement stroke	50mm*50mm
Injection control	software digitization

Light source system

Light source	Focus LED
Wavelength	450-480nm

Test function

Contact Angle Analysis (Complete Set)	●
Surface Free Energy Analysis	Zisman, OWRK, WU, WU 2, Fowkes, Antonow, Berthelot, EOS, Adhesion Work, Wetting Work, Spreading Coefficient
Surface interfacial tension	●
Forward and backward angle	●
Roll slip angle	--
Dynamic Video Measurement	●
Injection percentage	●
Sloping form	--
Captive bubble method	●
Top view measurement	●
3D form	optional
Temperature control platform	optional
Video shooting	●
Online measurement	●
Analysis method	Three-phase automatic
Data export	●
Programming test	--
Morphology spectrum	--
Fuzzy topography measurement	●
Batch sessile drop method	●
Software	Contact angle V3/V5

SDC-200S Scientific contact angle measuring instrument

Dynamic real-time fitting

Generate reports automatically

Innovative dual injection system

Automatic liquid injection system

Advanced Design R&D

Telecentric zoom zoom lens + LED cold light source + imported industrial camera = 0 imaging error

SDC-500Fully automatic contact angle measuring instrument

One-button automatic batch inspection, X, Y, Z three-axis automatic positioning

SDC-350Integral tilt type contact angle measuring instrument

It is suitable for studying the wettability, retention and adhesion of liquids on solid surfaces, and the overall tilt angle can be up to 180°

SDC-280FFiber type contact angle measuring instrument

Contact angle measuring instrument designed for measuring small products such as fibers and COF ultra-narrow edges

SDC-100Standard contact angle measuring instrument

Can measure sample surface hydrophobicity, wettability, surface tension and other test functions

SDC-80Standard Contact angle measuring instrument

Small and agile, compact and simple structure, easy to operate, can meet the most basic static contact angle measurement needs
